BRATECK Επιτοίχια βάση διπλού βραχίονα LPA63-466 για οθόνη 37-80", 40kg



BRATECK Επιτοίχια βάση διπλού βραχίονα LPA63-466 για οθόνη 37-80", 40kg
-Tilting Design: for better working angles
-Swiveling Arm(s): offer(s) maximum viewing flexibility (makes every seat the best seat)
-Built-In Level Adjustment: ensures perfect positioning
-Cable Management: elegantly hides any cables that are attached to displays
Τεχνικά Χαρακτηριστικά:
Product Category: Full-motion TV Wall Mount
Material: Steel
Metal Sheet Thickness: Wall Plate THK=2mm cold-rolled sheet, VESA Panel THK=1.8mm cold-rolled sheet, Bracket Arm THK=1.5mm cold-rolled sheet (Wall Plate THK=0.079" cold-rolled sheet, VESA Panel THK=0.071" cold-rolled sheet,Bracket Arm THK=0.059" cold-rolled sheet)
Pipe Size: 30x20x1.5mm Square Steel Tube
Surface Finish: Powder Coating
Color: Fine Texture Black
Dimensions: 468x655x420mm
Fit Screen Size: 37"-80"
Fit Curved TV: Yes
Mounting Hole Pattern: VESA & Universal
VESA Compatible: 75×75, 100×100, 100×150, 100×200, 150×100, 150×150, 200×100, 200×200, 300×200, 300×300, 400×200, 400×300, 400×400, 600×400
Max. VESA: 600x404mm
Weight Capacity: 40kg
Strength Tested: 2 Times Approved
Profile: 62~468mm
Tilt Range: +5°~-15°
Swivel Range: +60°~-60°
Screen Level: +3°~-3°
Screen Freely Tilting: No
Installation: Solid Wall,Double Stud(406mm/450mm)
Panel Type: Detachable Panel
Wall Plate Type: Fixed Wall Plate
AV Component Shelf: No
Direction Indicator: Yes
Cable Management: Yes
Anti-theft: No
Bubble Level: No
Περιεχόμενα συσκευασίας:
user manual
